101110FHAJPM406ZA FCI Rj45 Jack Connectors 10/100/1000Base-T

Name: 101110FHAJPM406ZA FCI Rj45 Jack Connectors 101001000BaseT
Brand: LINK-PP
Price: 1 USD

China 101110FHAJPM406ZA FCI Rj45 Jack Connectors 10/100/1000Base-T wholesale

Brand Name : LINK-PP

Model Number : 101110FHAJPM406ZA

Certification : UL,ROHS,Reach,ISO

Place of Origin : China

MOQ : 50/500/1000

Price : Supportive

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 4600K.PCS/Month

Delivery Time : Stock

Packaging Details : 50pcs/tray,1200pcs/carton

PN : 101110FHAJPM406ZA

Made In China : SM-LPJG17311A8NL

Application : 1000Base-T

Ethernet : GIG Ethernet

Port : 1,2,4,6,8 Flexible

Hipot : 1500V

Contact Now

101110FHAJPM406ZA FCI Rj45 Jack Connectors 10/100/1000Base-T

101110FHAJPM406ZA FCI

Trader Part Number

101110FHAJPM406ZA

Price Break	Unit Price	Extended Price
1-5	Free	Free
10-50	3.0	-
100-500	2.2	-
1,000-2,500	1.25	Dynamic
5,000	Dynamic	Dynamic
10,000	Dynamic	Dynamic
50,000	Negotiable	Negotiable
100,000	Negotiable	Negotiable
500,000	Negotiable	Negotiable

Made in China

SM-LPJG17311A8NL

Manufacturer

LINK-PP China

Description

Gigabit Rj45 Jack W/LED

Lead Free Status / RoHS Status

Lead free / RoHS Compliant

Quantity Available

2,000 PCS or 4 weeks

101110FHAJPM406ZA Electrical Specifications @25℃

1.Turn Ratio(%%P2%):
1CT∶1
2.Inductance OCL: 350uH MIN
@100KHz,0.1V,8mA DC Bias
3.Insertion Loss:
-1.0dB MAX @ 1～100MHz
-1.2dB MAX @ 100～125MHz
4.Return Loss(@100Ω):
-18dB MIN @ 1～30MHz
-16dB MIN @ 30～60MHz
-12dB MIN @ 60～80MHz
-10dB MIN @ 80～100MHz
5.Cross talk:
-30dB MIN @ 1～100MHz
6.Common Mode Rejection:
-30dB MIN @ 1～100MHz
7.Hipot Test: 1500Vrms MIN
8.Operatingt Temperature: 0 TO 70℃.

101110FHAJPM406ZA FCI Rj45 Jack Connectors 10/100/1000Base-T

Product Tags:

stacked rj45 connectors

rj45 magnetic jack

101110FHAJPM406ZA FCI Rj45 Jack Connectors 10/100/1000Base-T Images
